ASTRA-P14

The ASTRA-P14 represents the pinnacle of digital night vision technology, engineered for professional, law enforcement, and security applications. This advanced monocular system delivers unparalleled performance in the most challenging low light environments. In stock now — lead time 10–15 days from order.

MSRP$2,399

Key Features

1-inch high performance BSI CMOS solid-state image sensor

Superior low light performance

Spectral response range from 400nm to 1100nm

Minimum illumination as low as 0.00005Lux

800x600 image and OLED resolution

Super low latency at frame rate of 120Hz

IP67 waterproof and dustproof rating

Helmet mounting with Wilcox interface

Operation time up to 18+ hours (with 18650 battery)

Technical Specifications

Image Sensor

1-inch, 800x600 resolution

Light Sensitivity

Down to 0.00005 lux

Magnification

1x optical

Field of View

50° (> 40° x 30°)

Detection Range

935m (human), 1265m (vehicle)

Frame Rate

120Hz

Display

OLED, 800x600

Power Supply

One 16340 rechargeable lithium battery or compatible CR123A/18650

Operating Temperature

-20°C to +55°C (expandable to -40°C to +60°C)

Storage Temperature

-25°C to +55°C (expandable to -45°C to +70°C)

Dimensions

113×57×66 mm (18650 battery) / 95×57×66 mm (16340/CR123A)

Weight

< 299g (with 18650), < 263g (with 16340/CR123A)

Waterproof Rating

IP67

Shock Resistance

1.5M drop

Available Accessories

Helmet mount system

Protective carrying case

Additional battery pack via 9 pin connector (sold separately)

RS2 Data recording module via 9 pin connector (sold separately)

Frequently asked questions

Does the P14 have a zoom feature?⌄

No. The P14 is fixed at 1× magnification — there is no optical or digital zoom.
